Denago EV Nomad XL Electric Vehicle User Manual
Preface
Thank you for choosing the Denago EV Nomad XL electric vehicle! With a blend of innovative technology and exceptional design, the Denago EV Nomad XL is built for eco-friendly performance, durability, and reliability. It features advanced lithium-ion batteries, a highly efficient powertrain, and modern connectivity options. This manual is designed to help you safely operate, maintain, and care for your Nomad XL, ensuring the vehicle’s longevity and optimal performance. Please read it thoroughly to get the most from your electric vehicle.
Table of Contents
- Charging the Denago EV Nomad XL
- Safety Instructions for Denago EV Nomad XL
- Operating the Denago EV Nomad XL
- Understanding the Denago EV Nomad XL Controls
- Maintenance Guidelines for Denago EV Nomad XL
- Storage and Battery Care for Denago EV Nomad XL
- Bluetooth Connectivity & Apple CarPlay in Denago EV Nomad XL
- Troubleshooting and Technical Support for Denago EV Nomad XL
1. Charging the Denago EV Nomad XL
Components and Procedure:
- Battery Type: The Denago EV Nomad XL is powered by a LiFePO4 lithium-ion battery, which offers advanced safety, high efficiency, and long life. This battery is designed to provide excellent performance with minimal maintenance.
- Initial Charge:
- Fully charge your vehicle before using it for the first time. The intelligent charging system protects the battery from overcharging, extending its overall lifespan.
- Charging time: Typically 6-8 hours for a complete charge using the provided charger.
- Charging Routine:
- Recharge the battery after each use, as this will maximize performance and prolong its life.
- Avoid allowing the battery to deplete to critically low levels (below 20%).
- Monitor the battery’s State of Charge (SOC) on the display while charging.
- Charging Procedure:
- Connect the charger to a standard 120V outlet.
- Insert the charger plug into the vehicle’s charging port.
- The LED on the charger will indicate charging progress. When fully charged, the LED will turn green.
Safety Precautions:
- Use only the official Denago charger to ensure safe and efficient charging.
- Charge in a dry, well-ventilated area, away from extreme temperatures (above 45°C or below 0°C).
- Overnight charging is safe due to the integrated battery management system.
2. Safety Instructions for Denago EV Nomad XL
Critical Safety Features:
- Seatbelt Use: The Denago EV Nomad XL is equipped with seatbelts for all passengers. Always ensure seatbelts are properly fastened before starting the vehicle.
- Electromagnetic Parking Brake (EMB):
- The vehicle features an automatic electromagnetic parking brake that engages when the vehicle comes to a stop.
- For safety and battery conservation, ensure the EMB switch is in the OFF position when parked.
- To manually push or tow the vehicle, use the EMB switch to temporarily disengage the brake. Be aware this will gradually drain the battery.
- Adherence to Local Laws: As an LSV (Low-Speed Vehicle) or NEV (Neighborhood Electric Vehicle), the Denago EV Nomad XL is subject to local traffic regulations. Always follow speed limits and road laws specific to LSVs.
Driving Safety:
- Speed Control: The Denago EV Nomad XL’s top speed is limited to meet LSV regulations (25 mph or 40 km/h). Be mindful of speed limits in your area.
- Passenger Safety: Do not exceed the vehicle’s passenger capacity, and ensure all passengers are seated with seatbelts fastened.
- Impaired Driving: Never operate the vehicle under the influence of drugs or alcohol, as it impairs your judgment and reaction time.
3. Operating the Denago EV Nomad XL
How to Start and Stop the Denago EV Nomad XL:
- NFC Card Activation: The Denago EV Nomad XL uses an NFC card for secure access.
- To start the vehicle, simply touch the NFC card to the Denago logo on the dashboard.
- To stop the vehicle, touch the NFC card to the logo again.
- Forward/Reverse Control:
- Use the F/R switch to shift between forward and reverse. When in reverse, the vehicle will emit a warning sound.
- Ensure the vehicle is fully stopped before switching between forward and reverse gears.
Lighting and Indicator System for Denago EV Nomad XL:
- Daytime Running Lights (DRL): The Denago EV Nomad XL is equipped with signature daytime running lights for enhanced visibility during daylight hours.
- Rotate the switch to activate the DRLs, which use minimal battery power and stay on during low-light conditions.
- Low Beam and High Beam Headlights:
- Low beams are ideal for night driving, while high beams are used for extra visibility in low-traffic areas. To switch to high beams, push the light lever up.
- Brake and Turn Signal Indicators: Brake lights activate automatically when the brake pedal is pressed, ensuring rear visibility. The turn signals are operated via the steering column lever.
4. Understanding the Denago EV Nomad XL Controls
Key Control Components for Denago EV Nomad XL:
Accelerator Pedal:
- The electronic throttle control provides smooth and precise acceleration. Apply gentle pressure for gradual speed increase.
- Avoid excessive pressure on the accelerator to conserve energy and ensure smooth driving.
Brake Pedal:
- The Nomad XL is equipped with a hydraulic braking system that provides consistent, smooth deceleration. Press the brake pedal gently for a gradual stop.
- Emergency Braking: In case of an emergency, press the brake pedal firmly to engage full braking force.
Steering Wheel:
- The power-assisted steering allows easy maneuvering at all speeds. Avoid making sharp turns at high speeds to prevent rollover or loss of control.
Digital Dashboard:
- The dashboard displays vital information such as speed, battery level, total mileage, and warning lights (e.g., low battery, EMB status).
- The speedometer can be toggled between kilometers per hour (KM/H) and miles per hour (MPH) by holding the KM/H button for six seconds.
5. Maintenance Guidelines for Denago EV Nomad XL
Regular Maintenance for Denago EV Nomad XL:
Tire Maintenance:
- Tire pressure should be maintained at 20 psi for optimal performance and safety. Check tire pressure weekly.
- Inspect the tires for damage or wear before each ride. Replace the tires once the tread wears down to 1mm.
Battery Maintenance:
- Regularly check the battery for signs of physical damage, corrosion, or loose connections.
- Clean the battery terminals with a dry cloth and apply anti-corrosion treatment as needed.
Brake System Maintenance:
- Test the brakes weekly to ensure the vehicle stops effectively within the recommended stopping distance.
- If the brakes feel unresponsive or show signs of wear, contact a qualified technician for inspection and adjustment.
Steering System Maintenance:
- Ensure the steering operates smoothly without excessive play. If the steering feels loose or unresponsive, have it checked by a professional.
6. Storage and Battery Care for Denago EV Nomad XL
Preparing for Short-Term Storage of Denago EV Nomad XL:
Battery Management:
- Fully charge the battery before storing the vehicle.
- Turn off the EMB and power switch to prevent unnecessary battery drain during short-term storage.
Storage Environment:
- Store the Denago EV Nomad XL in a cool, dry place, away from direct sunlight, moisture, or extreme temperatures.
Preparing for Long-Term Storage (Over 3 Weeks) for Denago EV Nomad XL:
Battery Disconnection:
- Disconnect the battery if storing the vehicle for more than three weeks to avoid gradual discharge. Ensure the battery is fully charged before disconnection.
Vehicle Maintenance During Storage:
- Check the battery once a month to ensure it holds a charge.
- Keep the vehicle covered with a breathable fabric cover to protect it from dust and environmental damage.
7. Bluetooth Connectivity & Apple CarPlay in Denago EV Nomad XL
Bluetooth Pairing Instructions for Denago EV Nomad XL:
- Go to Settings > Bluetooth on your iPhone.
- Select “DENAGO” from the list of available devices.
- A Bluetooth Pairing Request code will appear on both your iPhone and the Nomad XL’s display. Confirm the code, then press “Pair.”
- To use Apple CarPlay, you will be prompted to sync contacts and favorites. Afterward, tap “Use CarPlay.”
Using Apple CarPlay in Denago EV Nomad XL:
- Apple CarPlay automatically connects wirelessly after pairing.
- Use CarPlay for hands-free navigation, messaging, and media playback, controlled via voice commands or the vehicle’s infotainment system.
8. Troubleshooting and Technical Support for Denago EV Nomad XL
Common Issues for Denago EV Nomad XL:
Battery Not Charging:
- Confirm the charger is securely connected to the vehicle and a working outlet.
- Inspect the battery terminals for corrosion. Clean them if necessary and attempt charging again.
Electromagnetic Parking Brake (EMB) Not Disengaging:
- Ensure the EMB switch is in the OFF position. If the issue persists, contact Denago support for troubleshooting assistance.
Speedometer Display Not Switching:
- Hold the “KM/H” button on the dashboard for six seconds to toggle between kilometers per hour and miles per hour.
Bluetooth Connectivity Issues:
- Unpair the device from both the Nomad XL and your iPhone, then reconnect by following the Bluetooth pairing instructions.
For further assistance, contact Denago customer support or refer to the FAQs and service center locator on the Denago website.
The next generation of Low Speed Vehicles is the DENAGO® NOMAD XL. This electric vehicle combines cutting-edge technology with exceptional performance, offering an unrivaled driving experience. With its sleek design and eco-friendly credentials, the NOMAD XL is perfect for those who seek style without compromising on sustainability. Glide through city streets or explore new horizons, all while enjoying the luxurious comfort and advanced features that set the DENAGO® EV NOMAD XL apart. Embrace innovation and redefine your ride with the DENAGO® EV NOMAD XL today!
Whether you’re commuting, exploring, or simply enjoying the drive, choose the DENAGO® NOMAD XL for a future-forward, high-performance experience. Upgrade your journey today with the DENAGO® NOMAD XL!
Experience the ultimate in eco-friendly transportation with the NOMAD XL LSV. This Low-Speed Vehicle (LSV) combines advanced electric technology with luxurious comfort, providing a smooth and stylish ride. Perfect for neighborhood commutes, recreational drives, or city errands, the NOMAD XL LSV offers a sustainable and efficient driving solution. With zero emissions, top-tier safety features, and a modern design, the NOMAD XL LSV is the ideal choice for those who value both performance and the environment. Upgrade your daily drive with the NOMAD XL LSV and embrace a greener future today!
Starting At $7995
Experience top-tier electric performance with the Denago® EV Nomad XL, starting at only $7,995. Enjoy exceptional comfort, advanced technology, and eco-friendly driving at an incredible value. Don’t miss this opportunity – upgrade to the Denago® EV Nomad XL today and revolutionize your ride!
2024 DENAGO® EV NOMAD XL SPECS
| Feature | Description |
|---|---|
| Model | Denago EV Nomad XL – Gray 2024 |
| Street Legal | Fully Street Legal |
| Battery Type | Lithium Battery |
| Top Speed | 25 MPH |
| Motor | 5kW AC Motor |
| Camera | Rear Camera |
| Power Outlet | 110V AC Outlet |
| Battery Specification | LiFePO4 Lithium Battery |
| Brakes | Four Wheel Hydraulic Brakes |
| Lights | LED Head and Tail Lights |
| Brake Lights | Yes |
| Front Light Bar | Yes |
| Front Brush Guard | Yes |
| USB Ports | USB Charging Ports |
| Tires | All Terrain Tires |
| Windshield Wiper | Manual |
| Seat Belts | Yes |
| Speedometer/Odometer | Yes |
| Hazard Lights | Yes |
| Side Mirrors | Yes |
| Rear Seat | Rear Flip Seat |
| Cup Holders | Yes |
| Warranty | 2 Year Parts, 5 Year Battery |
2024 DENAGO® EV NOMAD XL WARRANTY
Warranty Terms and Conditions for DENAGO EV Golf Carts
At Tigon Golf Carts, we prioritize the satisfaction and peace of mind of our customers. When you purchase a DENAGO EV golf cart from us, you are not just investing in a top-quality electric vehicle but also in a comprehensive warranty that ensures your cart remains in excellent condition.
Limited Lifetime Warranty
Coverage: DENAGO® EV (“Company”) offers a Limited Lifetime Warranty for new electric vehicles and associated batteries or vehicle chassis to be free from material or workmanship defects. This warranty covers parts only for the original purchaser.
DENAGO EV Corporation (“DENAGO EV”) warrants to the Original Purchaser or Lessee, subject to the terms and conditions outlined here, that its new vehicle or component purchased from DENAGO® EV or an Authorized Dealer or Distributor shall be free from defects in material and workmanship under normal use and service for the specified periods below.
Warranty Period: The warranty period begins on the vehicle’s retail date of purchase. For DENAGO® EV rental fleets, please refer to the DENAGO® EV Rental/Commercial Limited Warranty.
Components Warranty Coverage
- Aluminum Chassis: Lifetime
- LiFePO4 Battery: 5 Years (Full Replacement*)
- All Other Parts and Components: 2 Years
Exclusions
This warranty does not cover:
- Routine maintenance, normal wear and tear, proper tire pressure, and cosmetic deterioration.
- Damage from neglect, abuse, accident, unapproved parts or accessories, or external events such as vandalism or acts of nature.
- Repairs not performed at approved dealer locations (repairs by dealer personnel at retail customers’ residences are allowed).
- Costs for transportation to/from service locations.
- Fuses, decals (except safety decals), light bulbs, lubricants, trim pieces, seats, routine wear items such as brake shoes, brushes, bushings, mats and pads, tires, and maintenance adjustments.
- Cosmetic deterioration and items that deteriorate or fail due to exposure to environmental elements or ordinary wear and tear. This includes paint fading due to chronic sun exposure or improper storage.
Warranty Void Conditions
The warranty may be void if the vehicle/battery shows signs of:
- Neglected maintenance or usage outside the guidelines described in the Operator’s (Owner’s) Manual.
- Use of non-OEM (unapproved) parts, modifications, or alterations.
- Non-approved electrical installations.
Sole Remedy
If a defect arises, DENAGO® EV will, at its discretion, repair or replace the part with original OEM parts or reconditioned parts at the factory’s option. Defective parts replaced under the terms of this warranty are the property of DENAGO® EV and must be returned to DENAGO® EV upon request.
Liability
DENAGO® EV excludes liability for indirect damages, including but not limited to death, injury, or property damage, arising from product defects. All legal claims must be made within three months of the warranty claim’s origination.
Battery Warranty and Specifics
- The amp hour warranty period is recorded by DENAGO® EV.
- Battery warranty claims require DENAGO® EV specified testing.
- Non-factory additions directly to batteries will void the warranty.
- The 5-year full replacement battery warranty applies solely to personal-use vehicles and excludes commercial-use vehicles.*
Reserved Rights
DENAGO® EV reserves the right to inspect vehicles, modify designs, or assess warranty claims without needing to update previous products. Purchaser acknowledges that this warranty is the entire warranty provided by DENAGO® EV, and no exceptions or modifications to this warranty are valid without written approval from DENAGO® EV Corporation.
DENAGO® EV’S MAIN PRIORITY IS TO TAKE CARE OF ALL OUR DEALERS AND CUSTOMERS. YOU ARE OUR NUMBER ONE PRIORITY, AND WE WILL PROVIDE YOU WITH THE EXCELLENT CUSTOMER SERVICE YOU DESERVE 24/7.
Disclaimer
THIS LIMITED WARRANTY IS EXCLUSIVE. DENAGO® EV MAKES NO OTHER WARRANTY OF ANY KIND EXPRESSED OR IMPLIED. ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE THAT EXCEED THE OBLIGATIONS OR TIME LIMITS STATED IN THIS WARRANTY ARE HEREBY DISCLAIMED BY DENAGO® EV AND EXCLUDED FROM THE WARRANTY. THE REPAIR OF THE DEFECTIVE VEHICLE OR COMPONENT THEREOF IS THE SOLE REMEDY OF THE PURCHASER. DENAGO® EV MAKES NO OTHER REPRESENTATION OR WARRANTY OF ANY KIND, AND NO REPRESENTATIVE, EMPLOYEE, DISTRIBUTOR, OR DEALER OF DENAGO® EV HAS THE AUTHORITY TO MAKE OR IMPLY ANY REPRESENTATION, PROMISE, OR AGREEMENT THAT IN ANY WAY VARIES THE TERMS OF THE WARRANTY.
Warning
ANY MODIFICATION OR ALTERATION TO THE VEHICLE BEYOND FACTORY SPECIFICATIONS, INCLUDING THOSE THAT AFFECT THE WEIGHT DISTRIBUTION, STABILITY, OR SPEED OF THE VEHICLE, CAN CAUSE SERIOUS PERSONAL INJURY OR DEATH AND WILL VOID THIS WARRANTY IN ITS ENTIRETY.
| Warranty Component | Coverage Details |
|---|---|
| Coverage | Limited Lifetime Warranty for new electric vehicles and associated batteries or vehicle chassis to be free from material or workmanship defects. Parts only warranty for the original purchaser. |
| Warranty Period | Begins on the vehicle’s retail date of purchase. For rental fleets, see Rental/Commercial Limited Warranty. |
| Components Warranty Coverage | |
| Aluminum Chassis | Lifetime |
| LiFePO4 Battery | 5 Years (Full Replacement*) |
| All Other Parts and Components | 2 Years |
| Exclusions | |
| Routine Maintenance | Normal wear and tear, proper tire pressure, and cosmetic deterioration. |
| Damage | Neglect, abuse, accident, unapproved parts or accessories, external events like vandalism or acts of nature. |
| Repairs | Not performed at approved dealer locations (repairs by dealer personnel at retail customers’ residences are allowed). |
| Transportation Costs | To/from service locations. |
| Specific Parts | Fuses, decals (except safety decals), light bulbs, lubricants, trim pieces, seats, routine wear items (brake shoes, brushes, bushings, mats and pads, tires), maintenance adjustments, and cosmetic deterioration. |
| Warranty Void Conditions | Neglected maintenance, usage outside the Operator’s (Owner’s) Manual, non-OEM parts, modifications, non-approved electrical installations. |
| Sole Remedy | DENAGO® EV will repair or replace the defective part with original OEM parts or reconditioned parts at the factory’s option. Defective parts replaced are the property of DENAGO® EV. |
| Liability | DENAGO® EV excludes liability for indirect damages, including death, injury, or property damage arising from product defects. Legal claims must be made within three months of the warranty claim’s origination. |
| Battery Warranty Specifics | |
| Amp Hour Warranty | Recorded by DENAGO® EV. |
| Warranty Claims | Require DENAGO® EV specified testing. |
| Non-factory Additions | Direct additions to batteries will void the warranty. |
| 5-Year Full Replacement | Applies solely to personal-use vehicles, excludes commercial-use vehicles.* |
| Reserved Rights | DENAGO® EV reserves the right to inspect vehicles, modify designs, or assess warranty claims without needing to update previous products. |
| Disclaimer | This limited warranty is exclusive. DENAGO® EV makes no other warranty of any kind expressed or implied. Any implied warranties of merchantability or fitness for a particular purpose that exceed the obligations or time limits stated in this warranty are hereby disclaimed by DENAGO® EV and excluded from the warranty. The repair of the defective vehicle or component thereof is the sole remedy of the purchaser. DENAGO® EV makes no other representation or warranty of any kind, and no representative, employee, distributor, or dealer of DENAGO® EV has the authority to make or imply any representation, promise, or agreement that in any way varies the terms of the warranty. |
| Warning | Any modification or alteration to the vehicle beyond factory specifications, including those that affect the weight distribution, stability, or speed of the vehicle, can cause serious personal injury or death and will void this warranty in its entirety. |
For any warranty claims or inquiries, please contact: DENAGO® EV Parts & Service Phone: 833-965-3024
Email: cs@denagoev.com
Thank you for choosing Tigon Golf Carts and DENAGO EV. We are committed to ensuring your satisfaction and providing the support you need to enjoy your golf cart for years to come.
Tigon Golf Carts
Open 9AM ⋅ Closes 5 PM
www.tigongolfcarts.com
1-844-844-6638
GET 0% FINANCING FOR THE DENAGO® NOMAD XL!
Tigon Golf Carts proudly offers DENAGO® 0% vehicle financing, making it easier than ever to own your dream golf cart. With flexible payment options and competitive rates, we ensure that upgrading to an DENAGO® is not only exciting but also financially feasible for our customers, allowing you to hit the road in style without breaking the bank.
At Tigon Golf Carts, our DENAGO® NOMAD XL inventory boasts a diverse selection of high-quality golf carts designed to elevate your experience on the course. Whether you’re seeking luxury, performance, or versatility, we have the perfect DENAGO® NOMAD XL colors to suit your preferences and needs, ensuring every round is a memorable one.
As a verified DENAGO® dealer, Tigon Golf Carts provides customers with unparalleled access to genuine DENAGO® products, expert guidance, and exceptional service. Count on us for a seamless experience, from selecting the perfect DENAGO® models to ongoing support and maintenance, ensuring your golfing adventures are always extraordinary.
Tigon Golf Carts proudly offers DENAGO® Parts & Services, ensuring your golf carts maintain peak performance and reliability with top-notch components and expert maintenance solutions tailored to your needs. Trust us to keep your DENAGO® Parts running smoothly, ensuring your golfing experience is always exceptional.
Tigon Golf Carts proudly offers DENAGO® 0% vehicle financing, making it easier than ever to own your dream golf cart. With flexible payment options and competitive rates, we ensure that upgrading to an DENAGO® is not only exciting but also financially feasible for our customers, allowing you to hit the greens in style without breaking the bank.
Join the conversation at the NOMAD XL® Community Forums! Connect with fellow enthusiasts, share your experiences, and get the latest updates on the NOMAD XL®. Whether you’re a proud owner or considering your first purchase, our forums offer a wealth of knowledge, tips, and support. Discuss everything from performance enhancements to maintenance advice, and be part of a vibrant community that shares your passion for the ultimate electric vehicle. Dive into the NOMAD XL® Community Forums today and drive your experience to the next level!
